Announcing a New Altman Phoenix Family of Fixtures

Altman Lighting announces updates to the new PHX LIME chip. The product is billed as brighter, without any increase of power pull, meaning that mixing to white, users will see anywhere between a 1,000-2,000 more lumen increase in total brightness per fixture, per lens. While also providing the punchy independent saturates of Red, Green, and Blue the PHX line has been known for. This is made possible by splitting the LED only four times allowing Altman to deliver more power to the saturate chips than many other fixtures in the current market while still maintaining thousands of color combinations.

The new PHX LVD is a true "dim to 0" LED with a very smooth fade out and in. Many other LED products in the market that run off of dimmers have a "pop on" or "drop out" point which is not preferable for smooth dimming.

According to Nicolas Champion, VP of sales and marketing for Altman Lighting, "The LVD performance is similar to an incandescent dimming curve and can dim all the way to 0% very smoothly. Furthermore, the PHX LVD is forward or reverse phase compatible, meaning that it can work on almost all types of dimming systems, as long as the dimmer is big enough to handle the load of the fixture."

Champion emphasizes the cost savings that the new PHX line allows: "Customers can have a warm/cool White LED unit, without having to change their existing dimming infrastructure and may even be able to save their current lens tubes, as the new PHX fixtures also accept many standard industry lens tubes. It's the true meaning of plug and play when it comes to upgrading old or new systems."

The PHX1.5 LED 150W RGBL Array is a long throw LED profile spot that is completely convection cooled, making it well suited for any and all acoustically sensitive environments seeking to avoid the use of fans.

Additional features include:
• Red, Green, Blue, Lime LED Engine
• 360° rotating barrel
• 100 to 240 VAC 50/60Hz operation
• DMX512 in/thru via 5-pin XLR connector
• Compatible with DMX 512 and RDM protocols
• Multiple on-board control options: color fades and strobes
• Console free stand alone Player Mode
• Multiple Dimming Curves
• Dimming - Smoothing Mode
• 8-bit or 16-bit virtual dimming engine provides smooth, high quality fades and minimizes color shift during dimming

• Four different control settings of:
• 16-Bit Mode, Master Channel On (10 DMX Channels)
• 16-Bit Mode, Master Channel Off (8 DMX Channels)
• 8-bit Mode, Master Channel On (5 DMX Channels)
• 8-bit Mode, Master Channel Off (4 DMX Channels)
• 25.5lb (11.56kg)
• cETLus listed and CE marked (IP20 Rated for indoor use)

The PHX3.5 LED 340W RGBL Profile is a state of the art luminaire in function, style, and efficiency. Designed and engineered with a number of innovative details and features, this fixture enhances versatility and efficiency without sacrificing performance, the company says. New and innovative options make the PHX LED ellipsoidals well suited for theatres, special events, television studios, or wherever superior, energy efficient lighting performance is required.

Additional features include:
• Red, Green, Blue, Lime LED Engine
• 360° rotating barrel
• Locking Shutters
• 100 to 240 VAC 50/60Hz operation
• Yoke made from rigid flat steel with dual locking handles, two mounting positions and indexed tilt angle markings
• DMX512 in/thru via 5-pin XLR connector
• Compatible with DMX 512 and RDM protocols
• Multiple on-board control options: color fades and strobes
• Console free stand alone Player Mode
• Multiple Dimming Curves
• Dimming - Smoothing Mode
• 8-bit or 16-bit virtual dimming engine provides smooth, high quality fades and minimizes color shift during dimming

• Four different control settings of:
• 16-Bit Mode, Master Channel On (10 DMX Channels)
• 16-Bit Mode, Master Channel Off (8 DMX Channels)
• 8-bit Mode, Master Channel On (5 DMX Channels)
• 8-bit Mode, Master Channel Off (4 DMX Channels)
• 25.5lb (11.56kg)
• cETLus listed and CE marked (IP20 Rated for indoor use)

PHX LVD LED zoom and fixed focus profiles are state of the art luminaires in function, style, and efficiency. These profiles have been designed and engineered with a number of innovative details and features enhancing versatility and efficiency without sacrificing performance, the company says.

This makes the PHX LVD well suited for use in houses of worship, theatres, and small to large performance spaces where energy efficient lighting performance is required. Under Mains Dim Control these Units can plug directly into a theatrical phase cut dimmers whether they are forward or reverse phase, and are specially designed to replicate the smooth dimming curve of their incandescent counterparts. Fully locking shutters and a 360° rotating barrel help keep the artistic part of your fixtures' focus intact and easy to attain, with virtually no light leak. The aesthetic appearance and ergonomically designed function controls only add to the appeal.

Additional features include:
• 360° rotating barrel
• Heat resistant Plano-Convex lensing
• Die-cast aluminum and sheet metal fabrication
• Color frame, C-Clamp, soft focus pattern holder, safety cable and 5 foot PowerCON included
• Positive locking double-clutch fixture body
• Wide accessory slot with sliding cover for
motorized pattern devices or optional iris • Yoke made from rigid flat steel with dual locking handles, two mounting positions and indexed tilt angle markings
• 5°, 10°, 19°, 26°, 36° and 50° Fixed Focus Lenses
• 15°-35° and 25°-50° Zoom Lenses
• 25.5lb (11.56kg)
• cETLus listed and CE marked (IP20 Rated for indoor use)

For more product information, click here. To find your local Altman reseller, click here.
